*The Arkfeld ships in lockout mode. While in lockout mode, the red indicator at the bottom will light up for a short time. Press and hold the center button (about 1 second) until the flashlight turns on with the moonlight or laser, and the flashlight will be unlocked.
FAQ
Q1: How do I use the lock-out function?
A1: The Arkfeld ships in lockout mode. While in lockout mode, the red indicator underneath the switch will light up quickly. Press and hold the center button (about 1 second) until the flashlight turns on with the moonlight or laser setting. Then it is unlocked.
Q2: Why is there a horizontal line on the green beam point?
A2: There may be some dirt on the lens, just wipe it with a cleaning cloth.
Q2: Why is Arkfeld's laser not as bright as the Baldr S WML?
A3: The Arkfeld's laser is CLASS 1 with a max output of 0.39mW, while the laser of the Baldr S is CLASS 3R with a max output of 5mW.
MATERIALS
Body Material
Aluminum Alloy
GENERAL DATA
Beam Distance
331 ft (101 m)
Max Performance
1,000 lumens
Charging Type
MCC3 Magnetic USB Charging
Compatible Batteries
Built-in 1050mAh Lithium Polymer Battery
Max Light Intensity
2,560 candela
Light Source
High-Performance Neutral White LED (4000k~5000K), High-Performance Cool White LED (5700K~6700K)
Mode Operation
Central Button & Selector
LIGHTING LEVELS
Turbo
1,000~300 lumens
Run time Turbo
4 + 110 minutes
High
300~60 lumens
Run time High
126 + 34 minutes
Med
60 lumens
Run time Med
11 hours + 50 minutes
Low
15 lumens
Run time Low
41 hours
Moon
1 lumen
Run time Moon
8 days
Strobe
Yes
SOS / BEACON
No
TECHNICAL CHARACTERISTICS
Waterproof
IPX7
Weight
3.07 oz (87 g)(Battery Included)
Height
0.59 in (15 mm)
Length
4.33 in (110 mm)
Width
0.98 in (25 mm)
Packaging
Carton Box
Use
Lighting, Presentation, Pet Toy
PACKAGE CONTENTS
●
Arkfeld (Battery Included) x 1
●
MCC3 Magnetic USB Charging Cable x 1
●
User Manual x 1
