Universal Magnetic USB Charger

$9.95
Rating:
96% of 100
5 Reviews
SKU
UC#Charger

UC (Universal Battery Charger) is a universal magnetic USB charger for most single cylinder rechargeable lithium or NiMH batteries of variable sizes. *Not compatible with customized dual polarity batteries*

Buy Now
  • Description
  • Technical Details
  • Reviews


FEATURES

  • USB powered with a charging current of 750mA.
  • Compatible with lithium batteries with a rated voltage between 3.6V and 3.7V. NiMH batteries.
  • Charging for dummies. There is no need for matching the polarities, as the charger can automatically recognize them when in use.
  • All sizes compatible. It works perfectly on cylinder shaped batteries of variable diameters and lengths.
  • Tangle-free flat cable design. Easy for storing and organizing.
*To prevent a short circuit, DO NOT charge batteries with a positive AND negative polarity on the same side. This includes Olight customized batteries built for magnetic charging.



SPECIFICATIONS

Main MaterialSilicon (Cable wrap), rubber (body), aluminium alloy (battery polarity and connection cable)
Dimensions(L)300mm x(W)8.7mm x(TH)21mm
Weight20.5 g
ColorBlack(Cable), Blue(Cable Spliter)
Powered byCylinder shaped rechargeable lithium and NiMH batteries
Rated Voltage4.7V to 5.2V
Charging
  1. CC & CV rechargeable lithium batteries
  2. CC-DELTA V NiMH batteries
  3. Red indicator (Blinks 3 times per second) - Standby
  4. Red indicator - Charging
  5. Green indicator (steady) - Charging Completed
Max.Charging Current750mA
Max. Charging Voltage
  1. 4.25V for rechargeable lithium battery
  2. 1.45V for NiMH battery
Charging Cut-Off Points
  1. When the charging current drops down blow 100mA for re chargeable lithium battery.
  2. Delta V (when the voltage drops after it is fully charged) for NiMH battery.

OLIGHT PROMISE

CHARGER FEATURES
Slots1
Compatible Battery TypeLi-Ion(3.7V) and NiMh(1.2v)
AC Wall AdapterOptional
12V Car AdapterOptional
Max . Charging Current0.750
Detailed Charging Current 1 slot - 0.750A
Compatible with Lithium Cells10340, 10350, 10440, 10500, 12340, 12500, 12650, 13450, 13500, 13650, 14350, 14430, 14500, 14650, 16500, 16340(RCR123A), 16650, 17350, 17500, 17650, 17670, 18350, 18490, 18500, 18650, 18700, 20700, 21700, 22500, 22650, 25500, 26500, 26650
Compatible with NiMH/NiCD CellsAA, AAA, C, D, AAAA
Customer Reviews
  1. Great charge
    Service
    100%
    Easy to use. Charges fast and great for universal charging...

    Review by

    Posted on

  2. Service
    100%
    I have two of these for use with a small solar panel when hiking. It takes a little finesse sometimes to get the magnet on the positive terminal but the size and weight are excellent for keeping AAA and AA rechargeables charged. Great for emergency use as well, it takes no space in a pack or luggage.

    Review by

    Posted on

  3. Service
    80%
    Pros
    - Compact
    - Charges quickly
    - USB Powered
    - Indicator LED
    - Magnetic

    Cons
    - Poor fit on positive battery terminal RCR123A & 18650


    I really like this charger, it charges reasonably fast and has a status LED that is red when charging and green when the battery is fully charged. However there is one thing I do not care for. When you go to charge a battery and place the terminals on the negative side the fit is fine, however the Positive side will not fit around the battery terminal on RCR123A and 18650 batteries. This causes the charger to sit at an angle on the top of the battery terminal, making for an easily broken connection. Otherwise i think this charger is great.

    TL:DR
    I really like this charger but would like to see a slight change made to one or both of the contact points to better accommodate the positive terminals on 18650 and RCR123A batteries.

    Review by

    Posted on

  4. Service
    100%
    Works great and reasonably fast too. I like a lot.

    Review by

    Posted on

  5. Service
    100%
    This is a great product! I use it to charge my 18650's and other various batteries and it does the trick. It is super compact as well.

    Review by

    Posted on
