FAQ
Q1: O'Pen Glow vs. O'Pen Pro and O'Pen 2, what's the difference?
A1:
a. The O'Pen Glow adds a glowing tip, making it convenient for writing in dark environments.
b. The pen tip can be charged by simply inserting it into the charging dock, making charging effortless.
c. The white light switch is moved to the tail end, separate from the laser switch, much it easier to operate.
d. Added lock key function for safer portability.
Q2: Can O'Pen Glow refills be used in other O'Pens?
A2: The refill in O'Pen Glow also cartridges for O'Pen 2, O'Pen Pro, and O'Pen Mini.Please take note that there is a risk of the plastic cap at the end of the pen refill falling off during the installation of O'Pen Pro refill.
Q3: How to charge O'Pen Glow?
A3: Connect the charging base to the power supply, and insert the pen directly into the charging base to charge while the refill is in the retracted state.
Q4: Can O'Pen Glow use other brand refills?
A4: No, the O'Pen Glow's refill is electrically conductive, which is not possible with other refills.
MATERIALS
Body Material
AL6061-T6 Aluminum Alloy
GENERAL DATA
Beam Distance
46 ft (14 m)
Max Performance
120 lumens
Charging Type
Type-C Charging Cable
Compatible Batteries
110mAh Lithium Polymer Battery
Light Source
Pen Clip Light: High Performance White LED (5700K); Pen Tip Light High Performance White LED (4000K)
Form / Size Factor
Small Size
Series
Series O'Pen
LIGHTING LEVELS
High
120~60 lumens
Run time High
14 + 21 minutes
Med
60 lumens
Run time Med
45 minutes
Low
20 lumens
Run time Low
110 minutes
Moon
5 lumens
Run time Moon
5 hours
Pen Tip LED
0.2 lumens
Run time Pen Tip LED
2.5 hours
Strobe
No
SOS / BEACON
No
TECHNICAL CHARACTERISTICS
Waterproof
IPX4 (Upper part)
Weight
1.34 oz (38 g)
Length
Pen Light Length: 6.1 in (155 mm) (Tip Retracted); Charging Base Length: 1.52 in (38.5 mm)
Body Diameter
Pen Light Body Diameter: 0.5 in (12.7 mm); Charging Base Body Diameter: 0.91 in (23 mm)
Packaging
Carton Box
Use
Outdoors; Home
PACKAGE CONTENTS
●
O'Pen Glow ( Black Refill Included ) x 1
●
Blue Refill x 1
●
Type-C Charging Cable x 1
●
Charging Base x 1
●
Magnetic badge x 1
●
User Manual x 1
No comments yet
Post a comment >>
Share your experience
Chronological Order | Default Sort Order
This is truly an awesome tool and it fits right in my pocket!
Color： Black
O****
May 26, 2023, 00:47:07
Pretty cool pen. I like the laser feature. Writes smooth.
Color： OD Green
Anonymity
May 25, 2023, 00:38:33
My edc pen it does everything I need
Color： Black
N****
May 24, 2023, 22:45:23
Thank you very much, and thank you for the super fast shipping. I really love the updates. It was just what I have been looking for in a pin. Know if it could change colors that would be perfect.
Color： OD Green
K****
May 24, 2023, 22:45:17
The writing is smooth, the clip light is bright and the laser is as much fun as useful. The writing light is awesome for taking field notes at night or in low light situations in the truck.
Color： OD Green
Anonymity
May 24, 2023, 20:42:54
The laser, light and writing light are super useful.
Color： OD Green
S****
May 24, 2023, 18:27:41
This is a very functional item. It will be a very nice addition to my work EDC. One great bonus is that the cat really loves the laser.
J****
May 24, 2023, 15:26:52
This is my first full size O-pen! I really like it! I carry an O-pen mini edc, but this bad boy gets to stay on my desk so I can play with it when I'm bored at work! The small nitpicks I have are the clip is a tad too tight. It's kinda hard to clip on and off pockets. But since it's a desk pen it's not a huge deal. The bolt action is in a spot where you have to hold it in a certain orientation so it's not pushing into your hand. No biggie, it takes one second to turn the pen 180° so the bolt is facing you. And last but not least I don't really like how when you exit lockout modethe clip light stays on. I would prefer for it to blink, but then remain off. Again not a big issue, just have to click the button again. I DO LIKE the light on the tip, I think that's a great idea. I really like the laser (could be a bit brighter, though), I like how there are different brightness settings on the clip. And I like that you can take the top portion of to use the clip light and pen separately.
E****
May 24, 2023, 09:45:13
Clip too tight. Bolt is located so you have to hold certain way. Light stays on after exiting lockout. Other than those nitpicks I freaking LOVE it! Almost got the pro a few weeks ago. Glad I waited!
Color： Black
E****
May 24, 2023, 08:50:45
- 1
- 2
- 3
- 4
- 5
- 6
- 9
| File Name | Size | Link |
|---|---|---|
| O'Pen Glow User Manual.pdf | 1516KB | |
| O'Pen Glow Warning Manual.pdf | 762KB |
